CAPACITANCE SUBSTITUTION BOX

The unit is housed in a robust ABS case measuring 75 x 100 x 40 mm and has a high-quality rotary selector switch plus two 4 mm safety sockets.

With an easily selectable range of 11 preferred capacitors from 100µF to 0.47µF with the voltage rating of each range is 50 Volts.

PHY-00130/1          10 nF to 100 nF in steps of 100 pF

PHY-00130/2          100 nF to 1000 nF in steps of 100 pF

PHY-00130/3          1 kpF to 10 kpF in steps of 1 kpF

PHY-00130/4          10 kpF to 100 kpF in steps of 10 kpF

PHY-00130/5          100 kpF to 1000 kpF in steps of 100 pF
