ST.LOUIS MOTOR

The St. Louis Motor is a robust and easy-to-operate demonstration model for studying the construction and working principle of a DC electric motor. The apparatus demonstrates the conversion of electrical energy into mechanical energy through the interaction between the magnetic field and the current-carrying armature.

The unit consists of a 2-pole DC armature fitted with coils, mounted on an aluminium bracket. The armature shaft is supported on brass cone bearings for smooth rotation and is fitted with a split commutator for proper current reversal during operation.

Two permanent magnets mounted in adjustable holders provide the magnetic field required for motor operation. Electrical connections are made through binding posts and 4 mm socket terminals. The complete assembly is mounted on a sturdy Bakelite base for stability during classroom demonstrations.

Specifications:

• Item: St. Louis Motor
• Type: DC Electric Motor Demonstration Model
• Armature: 2-pole DC armature with coils
• Armature Support: Aluminium bracket
• Bearings: Brass cone bearings
• Commutator: Split commutator
• Magnets: Two permanent magnets
• Magnet Holders: Adjustable
• Electrical Terminals: Binding posts with 4 mm socket terminals
• Base: Sturdy Bakelite base
• Operation: Electrical input for demonstration of motor action
• Principle: Conversion of electrical energy into mechanical energy
• Application: Demonstration of DC motor construction and working
• Suitable For: Schools, colleges and educational physics laboratories
